Meta (Autonomous Lane Keeping Vehicle)

We are developing an autonomous vehicle capable of lane-keeping and detecting stop signs when moving through a course.

IntermediateFull instructions provided5
Meta (Autonomous Lane Keeping Vehicle)

Things used in this project

Hardware components

Webcam, Logitech® HD Pro
Webcam, Logitech® HD Pro
×1
BeagleBone Black
BeagleBoard.org BeagleBone Black
×1
USB Expansion HUB, USB 2.0 Powered
USB Expansion HUB, USB 2.0 Powered
×1
Test Accessory, USB Wi-Fi Dongle
Test Accessory, USB Wi-Fi Dongle
×1

Software apps and online services

OpenCV
OpenCV

Story

Read more

Schematics

Product Reviews

People are raving about our product!

Code

Our Code

Python
import cv2
import numpy as np
import math
import time
import Adafruit_BBIO.PWM as PWM

#throttle
throttle_pin="P8_13"

#Steering
steering_pin="P9_14"

# Default throttle speed
throttle_speed =  7.925

stop_threshold = 500
def check_for_stop_sign(frame):

	# Range of red in HSV
	lower_red = np.array([160,100,0], dtype="uint8")
	upper_red = np.array([180,255,255], dtype="uint8")

	# Filter out non red pixels and get count of number of red pixels
	mask = cv2.inRange(frame,lower_red, upper_red)
	num_red_px = cv2.countNonZero(mask)

	return num_red_px  > stop_threshold

def convert_to_HSV(frame):
	hsv = cv2.cvtColor(frame,cv2.COLOR_BGR2HSV)
	return hsv




######################################



default_angle = 7.5

camera = cv2.VideoCapture(0)
camera.set(cv2.CAP_PROP_FOURCC, cv2.VideoWriter_fourcc('X','2','6','4'))
camera.set(cv2.CAP_PROP_FRAME_WIDTH,150)
camera.set(cv2.CAP_PROP_FRAME_HEIGHT,120)

time.sleep(1)

# initialize steering and throttle
PWM.start(steering_pin,7.5,50,0)
PWM.start(throttle_pin,7.5,50,0)

time.sleep(2)

# Default throttle speed
PWM.set_duty_cycle(throttle_pin,throttle_speed)

# Default PWM associated with driving straight
default_duty = 7.5

lastTime = 0
lastError = 0

kp = 10
kd = .1

has_stopped_before = False


# Frame count
count = 1

while camera.isOpened():
    ret,frame = camera.read()

    frame = cv2.resize(frame,(320,180),interpolation = cv2.INTER_AREA)
    hsv = convert_to_HSV(frame)

    # Every 10 frames, check for a stopsign
    if (count % 10) == 0:

        stop_sign = check_for_stop_sign(hsv)

        if stop_sign and (has_stopped_before == False):

                # First sighting of stop sign, stop car
                PWM.set_duty_cycle(throttle_pin, 7.5)
                has_stopped_before = True
                time.sleep(2)

                # Continue after stopping for 2 seconds
                PWM.set_duty_cycle(throttle_pin, throttle_speed)
               stop_sign = False

        # Once a second stop sign is encountered, stop car indefinitely
        elif stop_sign and (has_stopped_before == True):
                print("DONE")
                while(1):
                    PWM.set_duty_cycle(throttle_pin, 7.5)
                    PWM.set_duty_cycle(steering_pin, 7.5)
        else:
            continue
    c+=1
    edges = detect_edges(frame)
    roi = region_of_interest(edges)
    line_segments = detect_line_segments(roi)
    lane_lines = average_slope_intercept(frame,line_segments)
    lane_lines_image = display_lines(frame,lane_lines)
    steering_angle = get_steering_angle(frame, lane_lines)
    heading_image = display_heading_line(lane_lines_image,steering_angle)
    #cv2.imshow("heading line",heading_image)


    now = time.time() # current time variable
    dt = now - lastTime
    deviation = -(steering_angle - 90) # equivalent to angle_to_mid_deg variable
    print("deviation = " , deviation)

    if deviation < 4 and deviation > -4: # do not steer if there is a 4-degree error range
        deviation = 0

    else:
        # Correct steering if deviation is large enough
        derivative = kd * (deviation - lastError) / dt / 90.0
        proportional = (kp * deviation) / 90 .0
        PD = float(default_duty + derivative + proportional)

        # Maximum steering conditions
        if PD > 9:
            PD = 9
        elif PD < 6:
            PD = 6

        # Correct steering
        PWM.set_duty_cycle(steering_pin, PD)

    lastError = deviation
    lastTime = time.time()

    key = cv2.waitKey(1)
    if key == 27:
        break

# Clean up camera and display
camera.release()
cv2.destroyAllWindows()
# Clean up GPIO
PWM.set_duty_cycle(throttle_pin, 7.5)
PWM.set_duty_cycle(steering_pin,7.5)
PWM.stop(steering_pin)
PWM.stop(throttle_pin)
PWM.cleanup()
