BeagleV™

The First Affordable RISC-V
Computer Designed to Run Linux
Truly Open Source
Open Source Software
Based on RISC-V Open Architecture
Open Hardware Design
Powerful and
Rich AI Features
Register Interest
Be the first to break free
with open source
software and hardware
Register Interest
Hardware Overview
Specifications
Processor
  • • RISC-V U74 Dual core with 2MB L2 cache @ 1.0GHz
  • • Vision DSP Tensilica-VP6 for computing vision
  • • NVDLA Engine 1 core (configuration 2048 MACs@800MHz )
  • • Neural Network Engine (1024MACs@500MHz)
Memory
  • • 8GB LPDDR4 (2 x 4GB LPDDR4 SDRAM)
Video
Processing
  • • Video Decoder (H264/H265) up to 4K@60FPS; Support Dual stream decoding for 2K@30FPS each
  • • Dual channels of ISP, each channel support up to 4K@30FPS
  • • 2 x MIPI-CSI, 1 x MIPI-DSI
  • • 1 x HDMI 1.4 support up to 1080P@60fps
  • • Support MIPI-CSI TX for video output after ISP and AI processing
  • • JPEG encoder/decoder
Peripherals
  • • 4 x USB 3.0 Ports
  • • 1 x Gigabit Ethernet
  • • 1 x 3.5mm Audio jack
  • • Support TRNG and OTP
  • • Support DMAC, QSPI and other peripheral
  • • Dedicated Audio Processing DSP and sub-system
  • • 40 Pin GPIO Header (28 x GPIO, I2C, I2S, SPI, UART)
  • • System boot from SD card
  • • 1 x Wi-Fi 2.4GHz b/g/n and Bluetooth 4.2
  • • Power with USB Type-C (5V@3A)
  • • 1 x Reset button and 1 x Power Button
Pinout
  • 3.3V Power
  • 5V Power
  • GPIO48 (I2C SDA)
  • 5V Power
  • GPIO47 (I2C SCL)
  • GND
  • GPIO46
  • GPIO14 (UART TX)
  • GND
  • GPIO13 (UART RX)
  • GPIO44
  • GPIO45
  • GPIO22
  • GND
  • GPIO20
  • GPIO21
  • 3.3V Power
  • GPIO19
  • GPIO18 (SPI MOSI)
  • GND
  • GPIO16 (SPI MISO)
  • GPIO17
  • GPIO12 (SPI SCLK)
  • GPIO15 (SPI CE0)
  • GND
  • GPIO11 (SPI CE1)
  • GPIO9
  • GPIO10
  • GPIO8
  • GND
  • GPIO6
  • GPIO7 (PWM0)
  • GPIO5 (PWM1)
  • GND
  • GPIO3
  • GPIO4
  • GPIO1
  • GPIO2
  • GND
  • GPIO0
Note:
All GPIOs can be configured to different functions including but
not limited to SDIO, Audio, SPI, I2C, UART and PWM
